Elevation Changes & Golf Club Distances
I often receive questions from golfers wanting to settle bets about something they have experienced on the golf course.
I received one from a Lawyer who had an Engineering friend debating him over distance gained or lost hitting a 240 yd downhill Drive. He said:
"My position is that the downhill drive hurt my distance, because the angle of approach to the fairway was much steeper hence I get less roll and less total distance despite more ball flight time.
Aron (my attorney) takes the opposite position, that in fact the extra 40 yards in the air more than compensates for the distance lost because of the angle.
Can you settle this?"
Here was my response:
" I would agree with your engineer friend. In most cases, the downhill drop increases the carry by the greater amount than the steep angle of attack decreases roll after impact.
On a horizontal hole, roll is about 10-15% of carry. Let's assume 10%.
240 yd carry + 24 yd roll = 264 yd
On a downhill shot, a 40 yd drop would result in an additional carry of 30-40 yd, depending on the trajectory. The roll would be less, due to the steeper angle of approach. Thus, the distance would be:
240 + 30 yd carry + 15 yd = 285 yd.
Even if there was no roll, due to very damp fairways, the downhill drive would be longer. "
not always obvious to golfers that when hitting uphill, you
need to hit more club and when hitting downhill, you need to hit
less club. The question is how much more or less. Of course, it
depends on many conditions. This page will discuss and deal with
the effect of elevation changes alone (without wind, rain, cold,
etc) so that you can improve your club selection and lower your
If you are interested in learning about effects of different altitudes on golf ball distance (5000 feet vs Sea Level, for instance), learn more HERE.
trajectory of a golf ball is now well understood. It depends on
ball velocity, trajectory, and spin as well as on air temperature,
humidity and density. Below is a graphic of the trajectory of a
golf ball hit with a driver, 5-iron, and
in the first part of each trajectory, the path of the ball steepens.
This is due to the lift created by the spin of the ball. Note as
well, that the trajectory of each is different at impact. The 9-iron's
impact is the steepest and the Driver's impact is the least steep.
Because of this, a Driver's range is more greatly affected by elevation
changes than a 5-iron and the 5-iron's is more greatly affected
than the 9-iron's. For every yard of fall, the Driver ball travels
farther. If on a tee shot, for instance, the ball were to land 20
yards below the tee in elevation, it would travel horizontally 15
The graph above was produced using my projectile model for a 6-iron. The green horizontal lines represent placements of the golf hole's green, relative to the position from which the ball is hit. If the hitting position and green are at the same elevation, the ball lands at about 162 yards.
If hitting uphill to a green elevated by 20 yards, the ball lands on the green at a horizontal distance of about 141 yards. Thus, the effective distance of the 6-iron is 21 yards shorter.
If hitting downhill to a green, 20 yards below, the ball lands ont he green at a horizontal distance of about 180 yards. Thus, the effective distance of the 6-iron is 18 yards longer.
my golf ball trajectory computer model to calculate the actual
distances uphill and downhill shots play for all the various
clubs. You can instantly download
my report along with similar
reports that explain how much wind affects your shots and how
much slope affects your putts. Get them here.
